Product Details
Place of Origin: China
Brand Name: Zhanlu
Model Number: SUP10
Payment & Shipping Terms
Minimum Order Quantity: Consultation
Price: Consultation
Packaging Details: Conventional packaging
Delivery Time: 5-8Workdays
Payment Terms: L/C, T/T
Supply Ability: Consulting service
Name: |
AISI/SAE6150 Spring Steel Round Bar |
Material: |
SUP10 |
Diameter: |
6.0mm-1200mm |
Length: |
2.5m-10m |
Type: |
Bright Round Bar |
Application: |
Spring |
Standard: |
AISI/SAE6150 |
Name: |
AISI/SAE6150 Spring Steel Round Bar |
Material: |
SUP10 |
Diameter: |
6.0mm-1200mm |
Length: |
2.5m-10m |
Type: |
Bright Round Bar |
Application: |
Spring |
Standard: |
AISI/SAE6150 |
SUP10 has good mechanical and technological properties, and high hardenability. The addition of vanadium refines the grain size of the steel, reduces overheating sensitivity, improves strength and toughness, has high fatigue strength, and has a high yield ratio, but has poor weldability and low cold deformation plasticity. SUP10 is a relatively advanced spring steel used as a high load important spring with a large cross-section, as well as a valve spring, piston spring, and safety valve spring with a working temperature of<300 ℃.
Supply Form & Size
| Form of Supply | Size(mm) | Length(mm) |
| Round bar | 6.0mm-1200mm | 2.5m-10m |
Chemical Composition&Related Specifications
| Grade | C | Si | Mn | P | S | Cr | Ni | Cu | V |
| SUP10 | 0.47～0.55 | 0.15～0.35 | 0.65～0.95 | ≤0.030 | ≤0.030 | 0.80～1.10 | ≤0.35 | ≤0.25 | 0.15～0.25 |
Brand comparison table
| AISI/SAE | DIN/EN | BS | JIS/KS | China |
| 6150 | 51CrV4(1.8159) | 51CrV4(1.8159) | SUP10 | 50CrVA |
